The Backbone of Every Great Ceiling — Precision-Engineered Galvanized Steel T-Grid That Holds Stronger, Lasts Longer.
Our Galvanized Steel Ceiling T Bar Grid System is the structural foundation for suspended gypsum and mineral fiber ceiling installations. Manufactured from high-strength hot-dip galvanized steel, these T-grid keels provide a rigid, corrosion-proof framework that supports ceiling tiles with long-term dimensional stability. As part of Shandong Ximai Lechuang Building Materials Co., Ltd.'s total ceiling solution, this T-bar system is designed to integrate seamlessly with our gypsum plasterboard tiles for a complete, code-compliant ceiling package.
Why Our T-Grid System?
Conventional ceiling grids fail in two ways: rust degradation in humid environments and insufficient load capacity over large spans. Our galvanized steel T-bars solve both. The zinc-coated surface treatment creates a sacrificial barrier against moisture and oxidation, while the precision-rolled T-profile delivers optimal strength-to-weight ratio. Whether you're outfitting a single office floor or a multi-building commercial complex, our grid system delivers consistent performance with minimal maintenance.
Key Applications
Office Buildings
● — open-plan suspended ceilings with integrated lighting, HVAC diffusers, and fire sprinklers
Retail & Shopping Malls
● — high-traffic public spaces requiring durable, rust-resistant ceiling frameworks
Hotels & Hospitality
● — decorative suspended ceilings in lobbies, corridors, and guest rooms
Hospitals & Healthcare
● — hygienic, non-combustible ceiling grids for cleanroom and patient areas
Educational Facilities
● — classrooms, auditoriums, and libraries with strict fire safety compliance
Residential Developments
● — multi-unit apartments and condominiums with standardized ceiling systems
Airports & Transport Hubs
● — large-span suspended ceilings in terminals and concourses
Section 4 — System Components (Complete Grid Solution)
A full T-grid ceiling system includes:
Main Tee
● (32×24×0.3×3600mm) — primary load-bearing runners
Cross Tee
● (26×24×0.3×1200mm / 26×24×0.3×600mm) — secondary intersecting members
Wall Angle
● (22×22×0.4×3000mm) — perimeter trim and edge support
| Attribute | Value |
| Product Name | T Bar Ceiling Grid / Light Steel Keel |
| Type | T-Grid Suspended Ceiling System |
| Model Number | Ceiling Grid |
| Brand | Ximai Lechuang |
| Place of Origin | Shandong, China |
| Material | Galvanized Steel (Hot-Dip Zinc Coated) |
| Surface Treatment | Galvanized (Zinc Plated) |
| Shape / Profile | T-Type |
| Thickness Options | 0.3mm (Standard) / 0.4mm (Heavy-Duty) |
| Length Options | 600mm / 1200mm / 3000mm / 3600mm |
| Main Tee Size | 32×24×0.3×3600mm |
| Cross Tee 1200 Size | 26×24×0.3×1200mm |
| Cross Tee 600 Size | 26×24×0.3×600mm |
| Wall Angle Size | 22×22×0.4×3000mm |
| Features | Corrosion-Resistant, Fireproof, Rustproof |
| Application | Indoor Ceiling Decoration, Suspended Ceiling System |
| Installation Method | Clip-Lock / Easy Installation |
| Design Style | Modern |
| Warranty | More Than 5 Years |
| Project Solution Capability | 3D Model Design, Cross Categories Consolidation, Total Solution |
| After-Sale Service | Online Technical Support |
| Customization | Minor & Full Customization Supported |
| Quantity (m²) | Unit Price (USD, approx.) |
| 500 – 999 | $0.69 |
| 1,000 – 9,999 | $0.65 |
| ≥ 10,000 | $0.62 |
| Item | Detail |
| Selling Unit | Single item (per piece / per linear meter) |
| Lead Time (≤1,000 m²) | 31 days |
| Lead Time (>1,000 m²) | To be negotiated |
| Shipping Terms | FOB / CIF — negotiable per order |
| MOQ | 500 m² |
1. Hot-Dip Galvanized Steel Premium zinc-coated steel delivers superior rustproof and corrosion-resistant performance — ideal for humid, coastal, and high-moisture environments.
2. T-Type Precision Profile Engineered T-bar cross-section (32×24mm, 26×24mm, 22×22mm) ensures perfect fit with standard ceiling tiles and panels.
3. 4 Standard Lengths Available in 600mm, 1200mm, 3000mm, and 3600mm — covering cross tees, main tees, and wall angles for a complete grid system.
4. Dual Thickness Options 0.3mm for standard commercial use and 0.4mm heavy-duty gauge for high-load or large-span installations.
5. Fireproof & Rustproof Non-combustible galvanized steel construction meets building code requirements — zero flame spread, zero smoke development.
6. Quick Clip-Lock Assembly Easy installation with standard T-grid connectors — reduces on-site labor time by up to 40% compared to traditional framing.
7. 5+ Year Warranty — industry-leading coverage backed by factory-direct quality control.
8. 3D Model Design Support — we provide CAD and 3D grid layout drawings for your project before production.
9. Total Project Solution — from ceiling grid design to cross-category consolidation (boards + grids + accessories), one supplier covers everything.
10. Full Customization — custom lengths, thicknesses, and surface finishes available for OEM/ODM projects.
11. Online Technical Support — real-time installation guidance and after-sale service for global projects.
Q1: What lengths are available for the T-bar grid?
A: Standard lengths are 600mm, 1200mm, 3000mm, and 3600mm. Custom lengths can be produced for bulk OEM orders.
Q2: What thickness should I choose — 0.3mm or 0.4mm?
A: 0.3mm is sufficient for most standard commercial ceiling applications. Choose 0.4mm for heavy-duty installations, large-span ceilings, or areas with additional suspended loads (lighting, signage, etc.).
Q3: Is this T-grid compatible with standard 595×595mm and 603×603mm ceiling tiles?
A: Yes. Our 600mm and 1200mm cross tees are designed to create 600×600mm and 1200×600mm modules, fitting all standard metric and imperial ceiling tile sizes.
Q4: Can I order the complete grid system (main tees + cross tees + wall angle) from you?
A: Absolutely. We offer a total ceiling solution — you can source gypsum boards, T-grid keels, and all accessories from a single supplier, saving logistics cost and coordination time.
Q5: Does the galvanized coating hold up in high-humidity environments?
A: Yes. The hot-dip galvanized zinc coating provides long-term corrosion resistance, making it suitable for bathrooms, kitchens, basements, coastal regions, and indoor swimming pool areas.
Q6: Do you provide installation drawings or design support?
A: Yes. We offer 3D model design and CAD layout drawings for your project, ensuring correct component quantities and grid spacing before production.
Q7: How long is the warranty?
A: We provide a 5+ year warranty on all galvanized steel T-grid products, backed by factory-direct quality assurance.
Q8: Can I get a sample set before placing a bulk order?
A: Yes. Sample kits including main tee, cross tee, and wall angle sections are available on request.
Q9: Is this product fire-rated?
A: Yes. The galvanized steel construction is non-combustible and meets standard building code requirements for fire-rated ceiling assemblies.
